Description
| MACHINE SIZE (Inch) | 52”x90” | 62”x90” |
|---|---|---|
| MOTOR (HP) (1 COL/2 COL) | 3/5 | 3/5 |
| PRINTING AREA (Inch) | 51”x90” | 61”x90” |
| OUTPUT (SHEETS/HR) | 2000 | 2000 |
| WT (APPROX) KGS(1 COL/2 COL) | 3000/4000 | 3300/4700 |
| FLOOR AREA (LxW) (1 COL/2 COL) | 220”x84”/265”x84” | 230”x96/280”x96” |
SPECIAL FEATURE OF “SUPERCUT” PRINTING MACHINE
- 1) High Accuracy and sharp Printing
- Start point registration:+_1.5mm
- Print registration before two printing stations +_1mm
- 2) Small Fonts, Barcodes, Reverse Printing & screen jobs can easily be printed on Our “Supercut” machine.
- 3) Heavy Duty One piece main Body.
- 4) Helical gear systems will latest technology for long life without lubrication And noiseless running.
- 5) SS gum Tray
- 6) Ex-tension feeding foldable platform ensuring operation friendly usage.
- 7) Delivery Collector table with both side gauges –reducing one labour.
- 8) Main Printing cylinder ground and hard chrome plated & finished wall thickness Of 14mm.
- 9) Electronic engraved Anilox roll
- 10) High Nitrile grade Rubber roll
- 11) Complete control panel with cabinet, MCB etc. and Portable remote with Digital counter sensor
